Material 2.4665

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

Standards

HDIN / EN	US-Standard	AFNOR	UNI	JIS	request
AlloyX	UNS N06002				request

Material Category: Nickellegierung

Chemical Composition

C %

Si %

Mn %

P %

S %

Al %

B %

Co %

Cr %

Cu %

Fe %

Mo %

Ni %

W %

0,05 - 0,15

max 1,00

max 0,020

max 0,015

max 0,5000

max 0,0100

0,50 - 2,50

20,50 - 23,00

max 0,50

17,00 - 20,00

8,00 - 10,00

Rest

0,20 - 1,00

Product Specifications

DIN 17744 (09/2002)
DIN 17750 (09/2002)
DIN 17752 (09/2002)
DIN 17753 (09/2002)
DIN EN 10088-1 (12/2014)
DIN EN 10302 (06/2008)
- WL

Mechanical Properties

lösungsgeglüht
0,2% Dehngrenze (Rp0,2)	Zugfestigkeit (Rm]	Bruchdehnung (A5, 65)	bei Temperatur
>= 270 N/mm²	>= 690 N/mm²	>= 30 %	~ 20 ° C
>= 260 N/mm²			~ 100 ° C
>= 245 N/mm²			~ 200 ° C
>= 230 N/mm²			~ 300 ° C
>= 215 N/mm²			~ 400 ° C
>= 200 N/mm²			~ 500 ° C
>= 195 N/mm²			~ 550 ° C
>= 190 N/mm²			~ 600 ° C
>= 180 N/mm²			~ 700 ° C
>= 165 N/mm²			~ 800 ° C
>= 140 N/mm²			~ 900 ° C
>= 80 N/mm²			~ 1.000 ° C
