Material 1.4034

Acero inoxidable

El grado 1.4034 es un acero inoxidable martensítico. 1.4034 es resistente en ambientes moderadamente agresivos y endurecible. A menudo se usa para cuchillos en la industria alimentaria (procesamiento).

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

Standards

HDIN / EN	US-Standard	AFNOR	UNI	JIS	request
X46Cr13	AISI 420 UNS S42000		X40Cr14		request

Material Category: Acero inoxidable

Chemical Composition

C %	Si %	Mn %	P %	S %	Cr %
0,43 - 0,50	max 1,00	max 1,00	max 0,040	max 0,015	12,50 - 14,50

Mechanical Properties

gehärtet	Zugfestigkeit (Rm)	Härte (HB 30)	Härte (HRC)
	~ 1.930 N/mm²	~ 535 HB 30	~ 55 HRC

vergütet	0,2% Dehngrenze (Rp0,2)	Zugfestigkeit (Rm)	Bruchdehnung (A 5, 65)	Kerbschlagarbeit KV (ISO-V/Charpy-V)	Probenlage
<= 160 mm	>= 650 N/mm²	850 - 1.000 N/mm²	>= 10 %	>= 12 Joule	längs
