Material 2.4952 / 2.4631

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

2.4952 / 2.4631

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
Alloy80A UNS N07080 request

Material Category: Nickellegierung

Chemical Composition

2.4952
C % Si % Mn % P % S % Al % B % Co % Cr % Cu %  Fe % Ni %  Ti %
0,04 - 0,10 max 1,00 max 1,00 max 0,020 max 0,015 1,0000 - 1,8000 max 0,0080 max 1,00 18,00 - 21,00 max 0,20 max 1,50 mind 65,00 1,80 - 2,70
2.4631
C % Si % Mn % P % S % Al % B % Co % Cr % Cu %  Fe % Ni %  Ti %
0,04 - 0,10 max 1,00 max 1,00 max 0,030 max 0,015 1,0000 - 1,8000 max 0,0080 max 2,00 18,00 - 21,00 max 0,20 max 1,50 Rest 1,80 - 2,70

Product Specifications

DIN 17742 (09/2002)
DIN EN 10088-1 (12/2014)
DIN EN 10090 (03/1998)
DIN EN 10269 (02/2014)
DIN EN 10302 (06/2008)

Mechanical Properties

DIN EN 10269 (02/2014)
Stähle und Nickellegierungen für Befestigungselemente für den Einsatz bei erhöhten und/oder tiefen Temperaturen.
lösungsgeglüht
+
ausscheidungsgehärtet		 0,2% Dehngrenze (Rp0,2) Zugfestigkeit (Rm] Einschnürung (Z) Kerbschlagarbeit KV2
(ISO-V/Charpy-V)		 Probenlage bei Temperatur
<= 160 mm       >= 20 Joule längs ~ -196 ° C
<= 160 mm >= 600 N/mm² 1.000 - 1.300 N/mm² >= 12 % >= 20 Joule längs ~ 20 ° C
<= 160 mm >= 595 N/mm² >= 1.000 N/mm²       ~ 50 ° C
<= 160 mm >= 586 N/mm² >= 975 N/mm²       ~ 100 ° C
<= 160 mm >= 577 N/mm² >= 950 N/mm²       ~ 150 ° C
<= 160 mm >= 568 N/mm² >= 900 N/mm²       ~ 200 ° C
<= 160 mm >= 564 N/mm² >= 900 N/mm²       ~ 250 ° C
<= 160 mm >= 560 N/mm² >= 900 N/mm²       ~ 300 ° C
<= 160 mm >= 550 N/mm² >= 900 N/mm²       ~ 350 ° C
<= 160 mm >= 540 N/mm² >= 900 N/mm²       ~ 400 ° C
<= 160 mm >= 530 N/mm² >= 900 N/mm²       ~ 450 ° C
<= 160 mm >= 520 N/mm² >= 890 N/mm²       ~ 500 ° C
<= 160 mm >= 510 N/mm² >= 880 N/mm²       ~ 550 ° C
<= 160 mm >= 500 N/mm² >= 850 N/mm²       ~ 600 ° C
<= 160 mm >= 480 N/mm²         ~ 650 ° C
