Material 1.1141
Case hardening steel
Buy at BASEDO STEEL C15E case hardening steel
As your partner for high-quality steels and non-ferrous metals, we also supply the case-hardening steel C15E, which is also traded under the material number 1.1141, in addition to many other materials. This is a so-called case hardening steel. As a rule, we supply C15 directly from stock in various raw dimensions and, if required, sawn to your desired dimensions. Of course, various rounds and plates are available from stock. For each delivery you will receive from us a material certificate of origin with the assured properties of the purchased raw material. We work exclusively with reliable international suppliers and producers from whom we purchase C15E directly ex works.
Important properties of the case hardening steel
C15E can be easily welded and cold worked. Due to its properties, C15E material is mainly used in mechanical engineering.
Direct & fast delivery from stock
We always keep a large stock of C15E case hardening steel in common dimensions for our customers. This enables us to meet even the larger requirements of trade, mechanical engineering and industry within a very short time. We can also supply special dimensions on request, as we offer a reliable cutting service that saws the required materials to exact dimensions as needed. Thanks to reliable logistic planning and an extensive fleet of vehicles, we are able to serve almost all delivery areas within a few days. If you need 1.0403 in consistent, outstanding quality, then send your inquiry now to BASEDO STEEL, your reliable partner for quality steels and non-ferrous metals of all kinds. Within a very short time, you will receive from us an inexpensive and non-binding offer for the quantity of C15E case-hardened steel you have requested. Of course, we are also available for deliveries with several call-offs if required. This saves you storage capacity, yet you always have sufficient quantities of C15E to fulfill your orders.
Get individual & personal advice
If you have any further questions about the material, our product range or the properties of the steels we offer, please do not hesitate to contact us. We will be pleased to advise you personally and in detail.
Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.
Standards
HDIN / EN | US-Standard | AFNOR | UNI | JIS | request |
---|---|---|---|---|---|
C15E/Ck15 C15 | AISI 1020 UNS G10200 | 1C15 | S15C S15CK | request |
Material Category: Case hardening steel
Applications
General Engineering
container construction
Heat Treatment
Carburizing temperature 880 - 980 C°, oil/water cooling
Core hardening temperature 880 - 920 C°, cooling oil / water
Surface hardening temperature 780 - 820 C°, oil cooling
Temper 150 - 200 C°, at least 1 hour, cooling in air
Weldability
The material C15E is easy to weld.
Chemical Composition
C % | Si % | Mn % | P % | S % |
0,12 - 0,18 | max 0,40 | 0,30 - 0,60 | max 0,035 | max 0,035 |
Product Specifications
DIN EN 10084
DIN EN 10132-2
DIN EN 10277
DIN EN 10297-1
DIN EN ISO 683-3
Mechanical Properties
1.1141 / C15E | |||
Hardness HBW | |||
Normalised annealed | 95 - 150 HBW | ||
Soft annealed | max 143 HBW | ||
Quenched and tempered at ~ 200 C° | Tensile strength RM | ||
<= 16 mm | >= 800 N/mm² | ||
16 - 40 mm | >= 600 N/mm² | ||
Rolled and peeled EN 10277 | Tensile strength RM | ||
16 - 40 mm | 330 - 600 N/mm² | ||
40 - 63 mm | 330 - 600 N/mm² | ||
63 - 100 mm | 330 - 600 N/mm² | ||
Hardness HBW | |||
16 - 40 mm | 98 - 178 HBW | ||
40 - 63 mm | 98 - 178 HBW | ||
63 - 100 mm | 98 - 178 HBW | ||
Soft-annealed and peeled | Hardness HBW | ||
16 - 40 mm | max 143 HBW | ||
40 - 63 mm | max 143 HBW | ||
63 - 100 mm | max 143 HBW | ||
Cold drawn | Tensile strength Rm | Yield strength Rp 0,2 | Elongation A5 % |
5 - 10 mm | 500 - 800 N/mm² | >= 380 N/mm² | >= 7 % |
10 - 16 mm | 480 - 780 N/mm² | >=340 N/mm² | >= 8 % |
16 - 40 mm | 430 - 730 N/mm² | >= 280 N/mm² | >= 9 % |
40 - 63 mm | 380 - 670 N/mm² | >= 240 N/mm² | >= 11 % |
63 - 100 mm | 340 - 600 N/mm² | >= 215 N/mm² | >= 12 % |
