Material 1.0301
acero endurecido
El material C 10 es un acero de cementación. Este material se utiliza para la construcción y piezas de máquinas. El material se puede cementar.
Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.
Standards
Material Category: acero endurecido
Applications
Ingeniería Mecánica
Heat Treatment
recocido suave (+A) 650 - 700 C°
Tratar al rango de dureza (+TH) 850 - 950 C°
Tratamiento sobre estructura de ferrita perlita y rango de endurecimiento (+FP) 900 - 1000 C°
Weldability
El material C10 es adecuado para soldar.
Chemical Composition
| C % | Si % | Mn % | P % | S % |
| 0,07 - 0,13 | max 0,40 | 0,30 - 0,60 | max 0,045 | max 0,045 |
Product Specifications
EN 10277-2
DIN EN 10084
Mechanical Properties
| 1.0301 / C10 Stabstahl behandelt auf Ferrit-Perlit Gefüge und Härtespanne | ||||||||||
| Abmessung Dimension mm | Streckgrenze Rp0,2 Yield Stress RP0,2 N/mm² | Zugfestigkeit Rm Tensile strength Rm N/mm² | Bruchdehnung Elongation A % | Einschnürung Reduct of Area Z % | Härte Hardness HB | Kerbschlagarbeit KV (ISO-V) Impact Test (Charpy-V) J | Einsatzhärtung im Kern Core case hardening | Weichgeglüht Soft annealed | Probenlage Sample | bei Temperatur at Temperature °C |
| <= 11 mm | >= 390 N/mm² | 640 - 780 N/mm² | >= 13 % | >= 35 % | >= 69 Joule | <= 11 mm | ||||
| <= 30 mm | >= 295 N/mm² | 490 - 640 N/mm² | >= 16 % | >= 45 % | >= 69 Joule | <= 30 mm | ||||
| < = 60 mm | 90 - 126 | max. 131 | ||||||||
