Material 2.4869

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

2.4869

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
Alloy80/20 UNS N06003 request

Material Category: Nickellegierung

Chemical Composition

C % Si % Mn % P % S % Al % Co % Cr % Cu % Fe % Ni %
max 0,15 0,50 - 2,00 max 1,00 max 0,020 max 0,015 max 0,3000 max 1,50 19,00 - 21,00 max 0,50 max 1,00 mind 75,00



Product Specifications

DIN 17470 (10/1984)
DIN 17742 (09/2002)
DIN 17750 (09/2002)
DIN 17753 (09/2002)

Mechanical Properties

Stabstahl Bruchdehnung (A5, 65) Zugfestigkeit (Rm)
    ~ 650 N/mm²
0,02 - 0,063 mm ~ 8 %
0,063 - 0,125 mm ~ 14 %
0,125 - 0,5 mm ~ 18 %
0,5 - 1 mm ~ 18 %
~ 1 mm ~ 25 %
