Material 2.4856

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

2.4856

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
Alloy625 UNS N06625 request

Material Category: Nickellegierung

Chemical Composition

C % Si % Mn % P % S % Al % Co % Cr % Cu % Fe % Mo % Nb % Ni % Ti %
0,03 - 0,10 max 0,50 max 0,50 max 0,020 max 0,015 max 0,4000 max 1,00 20,00 - 23,00 max 0,50 max 5,00 8,00 - 10,00 3,150 - 4,150 mind 58,00 max 0,40

Product Specifications

DIN 17744 (09/2002)
DIN 17750 (09/2002)
DIN 17751 (09/2002)
DIN 17752 (09/2002)
DIN 17753 (09/2002)
DIN EN 3671 (07/2007)
DIN EN 4379 (09/2008)
DIN EN 10088-1 (12/2014)
DIN EN 10095 (12/2018 (05/1999))

Mechanical Properties

DIN 17752 (09/2002)
Stangen aus Nickel und Nickel-Knetlegierungen - Eigenschaften
Stabstahl
weichgeglüht 0,2% Dehngrenze (Rp0,2) 1% Dehngrenze (Rp1,0) Zugfestigkeit (Rm] Bruchdehnung (A5, 65) Härte [HBW]
<= 100 mm >= 415 N/mm² >= 445 N/mm² >= 830 N/mm² >= 30 % <= 240 HBW
100 - 250 mm >= 345 N/mm² >= 375 N/mm² >= 760 N/mm² >= 30 % <= 240 HBW
lösungsgeglüht 0,2% Dehngrenze (Rp0,2) 1% Dehngrenze (Rp1,0) Zugfestigkeit (Rm] Härte [HBW]
<= 250 mm >= 275 N/mm² >= 305 N/mm² >= 690 N/mm² <= 240 HBW
