Material 2.4668

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

2.4668

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
Alloy718 UNS N07718 request

Material Category: Nickellegierung

Chemical Composition

C % Si % Mn % P % S % Al % B % Co % Cr % Cu % Fe % Mo % Nb % Ni % Ti %
0,02 - 0,08 max 0,35 max 0,35 max 0,015 max 0,015 0,3000 - 0,7000 0,0020 - 0,0060 max 1,00 17,00 - 21,00 max 0,30 Rest 2,80 - 3,30 4,700 - 5,500 50,00 - 55,00 0,60 - 1,20



Product Specifications

DIN 17744 (09/2002)
DIN 17750 (09/2002)
DIN 17752 (09/2002)
DIN 17753 (09/2002)
DIN EN 10088-1 (12/2014)
DIN EN 10269 (02/2014)
DIN EN 10302 (06/2008)
DIN SE 201 (10/1992)
- WL



Mechanical Properties

DIN EN 10269 (02/2014)
Stähle und Nickellegierungen für Befestigungselemente für den Einsatz bei erhöhten und/oder tiefen Temperaturen.
Stabstahl
weichgeglüht 0,2% Dehngrenze (Rp0,2) Zugfestigkeit (Rm] Bruchdehnung (A5, 65) Kerbschlagarbeit KV2
(ISO-V/Charpy-V)		 bei Temperatur
<= 160 mm   >= 1.030 N/mm² >= 12 % >= 12 J ~ 20 ° C
<= 160 mm >= 1.030 N/mm²     >= 12 J ~ 20 ° C
<= 160 mm >= 880 N/mm²       ~ 300 ° C
<= 160 mm >= 865 N/mm²       ~ 400 ° C
<= 160 mm >= 860 N/mm²       ~ 500 ° C
<= 160 mm >= 860 N/mm²       ~ 600 ° C
