Material 2.4660

Nickellegierung

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

2.4660

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
Alloy20CB3 UNS N08020 request

Material Category: Nickellegierung

Chemical Composition

C % Si % Mn % P % S % Co % Cr % Cu % Fe % Mo % Ni % --
max 0,07 max 1,00 max 2,00 max 0,025 max 0,015 max 1,50 19,00 - 21,00 3,00 - 4,00 Rest 2,00 - 3,00 32,00 - 38,00 Nb >= 8 x C <= 1,00



Product Specifications

DIN 17744 (09/2002)
DIN 17750 (09/2002)
DIN 17751 (09/2002)
DIN 17752 (09/2002)
DIN 17753 (09/2002)



Mechanical Properties

DIN 17752 (09/2002)
Stangen aus Nickel und Nickel-Knetlegierungen - Eigenschaften.
Stabstahl
weichgeglüht 0,2% Dehngrenze (Rp0,2) 1% Dehngrenze (Rp1,0) Zugfestigkeit (Rm] Bruchdehnung (A5, 65)
<= 90 mm >= 240 N/mm² >= 270 N/mm² >= 550 N/mm² >= 40 %
