Material 2.4068

Nickellegierung

Nickel 201

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

Standards

HDIN / EN	US-Standard	AFNOR	UNI	JIS	request
Nickel201 LC-Ni99	UNS N02201				request

Material Category: Nickellegierung

Chemical Composition

C %	Si %	Mn %	S %	Cu %	Fe %	Mg %	Ni %	Ti %
max 0,02	max 0,25	max 0,35	max 0,005	max 0,25	max 0,40	max 0,150	mind 99,00	max 0,10

Product Specifications

DIN 17740 (09/2002)
DIN 17750 (09/2002)
DIN 17751 (09/2002)
DIN 17752 (09/2002)
DIN 17753 (09/2002)

Mechanical Properties

DIN 17752 (09/2002) Stangen aus Nickel und Nickel-Knetlegierungen - Eigenschaften.
Stabstahl
weichgeglüht	0,2% Dehngrenze (Rp0,2)	1% Dehngrenze (Rp1,0)	Zugfestigkeit (Rm]	Bruchdehnung (A5, 65)	Härte [HBW]
2 - 55 mm	>= 80 N/mm²	>= 105 N/mm²	>= 340 N/mm²	>= 40 %	<= 130 HBW

1/2 hart	0,2% Dehngrenze (Rp0,2)	Zugfestigkeit (Rm]	Bruchdehnung (A5, 65)	Härte [HBW]
2 - 50 mm	>= 150 N/mm²	>= 430 N/mm²	>= 15 %	~ 150 HBW
