Material 1.4961

High-temperature resisting steel and alloy

The material 1.4961 is a austenitic stainless steel and is additonally alloyed with niobium. Niobium is used to stabilize, thus the material has a very good resistance to intergranular corrosion. Furthermore, the material also hot hard and therfore often find application in heat exchangers and turbine construction.

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

Standards

HDIN / EN	US-Standard	AFNOR	UNI	JIS	request
X8CrNiNb16-13	AISI 347H UNS S34709			SUS347HFB SUS347HTB SUS347HTP	request

Material Category: High-temperature resisting steel and alloy

Chemical Composition

C %	Si %	Mn %	P %	S %	Cr %	Ni %	-
0,04 - 0,10	0,30 - 0,60	max 1,50	max 0,035	max 0,015	15,00 - 17,00	12,00 - 14,00	Nb >= 10xC <=1,20

Mechanical Properties

vergütet
0,2% Dehngrenze (Rp0,2)	Zugfestigkeit (Rm)	Bruchdehnung (A 5,65)	Kerbschlagarbeit (DVM)	Kerbschlagarbeit KV (ISO-V/Charpy-V)	Zeitstandfestigkeit 1.000 h	Zeitstandfestigkeit 10.000 h	Zeitstandfestigkeit 100.000 h	Warmfestigkeit	bei Temperatur
								~ 650 °C
>= 205 N/mm²	510 - 690 N/mm²	>= 35 %	>= 85 Joule	>= 65 Joule					~ 20 °C
>= 175 N/mm²									~ 100 °C
>= 157 N/mm²									~ 200 °C
>= 137 N/mm²									~ 300 °C
>= 128 N/mm²									~ 400 °C
>= 118 N/mm²									~ 500 °C
>= 118 N/mm²					~ 304 N/mm²	~ 230 N/mm²	~ 170 N/mm²		~ 550 °C
>= 113 N/mm²					~ 230 N/mm²	~ 157 N/mm²	~ 94 N/mm²		~ 600 °C
					~ 167 N/mm²	~ 103 N/mm²	~ 64 N/mm²		~ 650 °C
					~ 118 N/mm²	~ 64 N/mm²	~ 34 N/mm²		~ 700 °C
						~ 44 N/mm²	~ 20 N/mm²		~ 750 °C
