Material 1.4301

Stainless steel

Grade 1.4301 is an austenitic stainless steel. 1.4301 ist he standard stainless steel grade. Because of its good corrosion resistance and its process ability it is common worl-wide.

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

1.4301

Standards

HDIN / EN US-Standard AFNOR UNI JIS request
X5CrNi18-10 X5CrNi189 AISI 304 AISI 304N UNS S30400 UNS S30451 X5CrNi1810 X5CrNi1810KG X5CrNi1810KW X5CrNi1810KT SUS304 SUS304A SUS304-CSP SUS304FB SUS304HTF SUS304TB SUS304TBS SUS304TF SUS304TKA SUS304TKC SUS304TP SUSF304 request

Material Category: Stainless steel

Chemical Composition

C % Si % Mn % P % S % Cr % N % Ni %
max 0,07 max 1,00 max 2,00 max 0,045 max 0,015 17,50 - 19,50 max 0,100 8,00 - 10,50



Mechanical Properties

lösungsgeglüht

0,2% Dehngrenze (Rp0,2)
bei Temperatur

 0,1% Dehngrenze (Rp0,1) Zugfestigkeit (Rm) Bruchdehnung (A5, 65) Einschnürung (Z) Härte (HB 30) Kerbschlagarbeit KV
(ISO-V/Charpy-V)		 Probenlage
<= 160 mm       >= 45 %     >= 100 Joule längs
160 - 250 mm       >= 35 %     >= 60 Joule längs
<= 250 mm >= 190 N/mm² >= 225 MPa 500 - 700 MPa   >= 60 % <= 215 HB 30   längs
  >= 155 N/mm² / ~ 100 ° C
  >= 140 N/mm² / ~ 150 ° C
  >= 127 N/mm² / ~ 200 ° C
  >= 118 N/mm² / ~ 250 ° C
  >= 110 N/mm² / ~ 300 ° C
  >= 104 N/mm² / ~ 350 ° C
  >= 98 N/mm² / ~ 400 ° C
  >= 95N/mm² / ~ 450 ° C
  >= 92 N/mm² / ~ 500 ° C
  >= 90 N/mm² / ~ 550 ° C
