Material 1.1221

Vergütungsstahl

Do you have any questions about the material or would you like to order? Complete our inquiry form, it`s free of charge and without obligation. We will get in touch with you in order to provide you with more information.

Standards

HDIN / EN	US-Standard	AFNOR	UNI	JIS	request
C60E Ck60 C60	AISI 1060 AISI 1064 UNS G10600 UNS G10640			S58C S60C-CSP S60CM S65C-CSP S65CM	request

Material Category: Vergütungsstahl

Chemical Composition

C %	Si %	Mn %	P %	S %	Cr %	Mo %	Ni %
0,57 - 0,65	max 0,40	0,60 - 0,90	max 0,030	max 0,035	max 0,40	max 0,10	max 0,40

Mechanical Properties

weichgeglüht

Härte (HB 30)

<= 241 HB 30

abgeschreckt Stirnabschreckversuch nach Jominy
<= 1 mm	60 - 67 HRC

vergütet	Streckgrenze (Re)	Zugfestigkeit (Rm)	Bruchdehnung (A5, 65)	Einschnürung (Z)
<= 16 mm	>= 580 N/mm²	850 - 1.000 N/mm²	>= 11 %	>= 25 %
17 - 40 mm	>= 520 N/mm²	800 - 950 N/mm²	>= 13 %	>= 30 %
41 - 100 mm	>= 450 N/mm²	750 - 900 N/mm²	>= 14 %	>= 35 %

Band gehärtet	Härte (HV)
<= 2 mm	<= 670 HV
